Factory Cat Micro-HD 25C Traction Drive
The Ultimate Hybrid: Sweeps, Scrubs, and Climbs with Ease.
The Factory Cat Micro-HD 25C is the most versatile industrial walk-behind on the market. By combining a compact chassis with Cylindrical technology and a dedicated Traction Drive, this machine solves the two biggest headaches in floor maintenance: pre-sweeping and operator fatigue.
The “C” system features dual counter-rotating brushes that sweep small debris—metal shavings, wood chips, and gravel—into an onboard hopper while simultaneously scrubbing the floor. No more clogged squeegees or streaky floors. With the power of the Traction Drive, this machine does all the work, even on inclines or heavy-grease environments.
Key Features
- Cylindrical Sweeping & Scrubbing: Eliminate the broom. Two 750 RPM brushes pick up solid debris while deep-cleaning grout lines and textured surfaces in a single pass.
- Independent Traction Drive: Powered by a high-torque, all-gear transaxle, the Micro-HD 25C moves effortlessly in forward and reverse. It’s perfect for facilities with ramps or operators who need to cover large areas without pushing.
- Industrial Build Quality: This isn’t a plastic commercial unit. It features a 1/8″ powder-coated steel frame, stainless steel hardware, and heavy-duty poly tanks designed for the rigors of manufacturing.
- Superior Water Recovery: A high-performance 3-stage vacuum motor and an industrial-grade curved squeegee leave your floors bone-dry, reducing the risk of slip-and-fall accidents.
- “Tip-Back” Accessibility: For the easiest maintenance in the industry, the tank tips back to provide total, toolless access to the batteries, motors, and internal plumbing.
Technical Specifications
| Feature | Specification |
| Scrub Path | 25 inches (64 cm) |
| Brush Type | Dual Cylindrical (Counter-Rotating) |
| Drive System | 0.75 hp Power Traction Drive |
| Solution Tank Capacity | 13 Gallons (49 Liters) |
| Recovery Tank Capacity | 15 Gallons (57 Liters) |
| Brush Speed | 750 RPM |
| Brush Motors | (2) 0.75 hp Motors |
| Down Pressure | Adjustable; Up to 90 lbs |
| Cleaning Productivity | Up to 25,641 sq. ft. / hr |
| Battery Run Time | Up to 3.5 Hours |
| Dimensions (L x W x H) | 48″ x 21″ x 39″ |
Why Choose the Micro-HD 25C?
“A Big Machine in a Small Frame.” The Micro-HD 25C is the “Swiss Army Knife” of floor scrubbers. It’s small enough to navigate through a standard door, but because it sweeps while it scrubs, it outperforms machines twice its size in dirty, debris-heavy environments like machine shops or warehouses.
Ideal Applications:
- Machine Shops: Picks up metal turnings and coolant in one pass.
- Woodworking Facilities: Handles sawdust and wood chips without clogging.
- Food Processing: Deep-cleans textured floors and grout lines easily.
- Warehouses: Navigates narrow aisles while handling pallet debris.
- Automotive Shops: Effortlessly cleans grease and small parts off the floor.
Stop Cleaning Twice.
The Micro-HD 25C sweeps and scrubs so you don’t have to. Contact us today to schedule a free on-site demo or to request a custom quote.
